2600-12S Turnlock Fastener Stud Assembly

NSN
5325-00-606-8252
ECCN
EAR99
Schedule
7318.15.5000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel
Distance From Engaging Member To Largest Bearing Surface Of Head
Between 0.871 inches and 0.887 inches
Drive Type
Slotted
Eyelet Length
0.322 inches
Eyelet Outside Diameter
Between 0.244 inches and 0.250 inches
Material Accommodated Thickness
Between 0.360 inches and 0.389 inches
Securing Device Type
Washer
Stud Assembly Style
Stud assembly
Turnlock Stud Head Style
Fillister
Diameter
0.303 inches
