26S51-5 Turnlock Fastener Stud Assembly

ECCN: EAR99
Schedule: 7318.15.5030

Price per Unit $10.50

Units per Pack 5

Price per Pack $52.50

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 5

Total Unit Quantity:

Total Packs 1

Total Price $52.50

Add item to quote

Material

Steel stud

Surface Treatment

Qq-p-35 federal specification single treatment response

Distance From Engaging Member To Largest Bearing Surface Of Head: 0.671 inches
Drive Type: Cross recess
Eyelet Length: 0.332 inches
Eyelet Outside Diameter: Between 0.244 inches and 0.250 inches
Material Accommodated Thickness: Between 0.150 inches and 0.179 inches
Material Specification: Qq-s-766 federal specification single material response eyelet
Securing Device Type: Spring
Stud Assembly Style: Stud assembly
Turnlock Stud Head Style: Fillister
Diameter: Between 0.298 inches and 0.308 inches
