4002-6SW Turnlock Fastener Stud Assembly

NSN
5325-00-584-1360
ECCN
EAR99
Schedule
7318.15.5000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel comp 302 ejector spring
Surface Treatment
Qq-p-35 federal specification single treatment response
Distance From Engaging Member To Largest Bearing Surface Of Head
Between 0.573 inches and 0.588 inches
Eyelet Length
0.322 inches
Eyelet Outside Diameter
Between 0.341 inches and 0.348 inches
Head Length
Between 0.850 inches and 0.890 inches
Material Accommodated Thickness
Between 0.201 inches and 0.230 inches
Stud Assembly Style
Stud assembly
Turnlock Stud Head Style
Flat countersunk wing
