4002-H Metallic Grommet

ECCN: EAR99
Schedule: 4016.93.0000

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Surface Treatment

Type 3 assn standard single treatment response astm b633

Distance Between Flanges: Between 0.167 inches and 0.173 inches
Eyelet Height: Between 0.193 inches and 0.201 inches
Eyelet Inside Diameter: Between 0.354 inches and 0.358 inches
Iii Material: Steel
Largest Outside Diameter: Between 0.617 inches and 0.625 inches
Material Specification: Astm a547 assn standard single material response
Smallest Outside Diameter: Between 0.467 inches and 0.473 inches
Turnlock Eyelet Style: Eyelet
