40S5-16 Turnlock Fastener Stud Assembly

NSN
5325-00-078-7560
ECCN
EAR99
Schedule
7318.15.5030
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel comp 302 pin
Surface Treatment
Qq-p-35 federal specification single treatment response
Distance From Engaging Member To Largest Bearing Surface Of Head
Between 0.843 inches and 0.873 inches
Drive Type
Slotted
Eyelet Length
0.257 inches
Eyelet Outside Diameter
Between 0.341 inches and 0.348 inches
Material Accommodated Thickness
Between 0.501 inches and 0.530 inches
Stud Assembly Style
Stud assembly
Turnlock Stud Head Style
Flat countersunk
Diameter
0.380 inches
