42FLW624 Self-Locking Extended Washer Nut

NSN: 5310-01-357-7668
ECCN: EAR99
Schedule: 7318.22.0000

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote

Material

Steel

Surface Treatment

Qq-p-416 federal specification single treatment response

Thread Class

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.375 inches

Criticality Code Justification: Spcl
Hardness Rating: Between 34.0 rockwell c and 43.0 rockwell c
Locking Feature: Free-running all metal design
Material Specification: Ms6280 assn standard single material response
Nut Style: Double hexagon
Overall Height: Between 0.428 inches and 0.448 inches
Special Features: Used on (97153) 3-1505 wheel assy's of f-16 nlg acft
Special Test Features: Must be qualified in accordance with applicable oem wheel qualification specification
Tempurature Rating: 450.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 24
Washer Outside Diameter: Between 0.614 inches and 0.634 inches
Washer Thickness: Between 0.046 inches and 0.066 inches
Width Across Flats: Between 0.492 inches and 0.502 inches
