82-19-180-20 Turnlock Fastener Stud

ECCN
EAR99
Schedule
7318.15.5000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel comp 302
Surface Treatment
Qq-p-35 federal specification single treatment response
Drive Type
Cross recess
Grip Length
Between 0.315 inches and 0.335 inches
Material Accommodated Thickness
Between 0.17 inches and 0.189 inches
Material Specification
Qq-s-763 federal specification single material response
Securing Device Type
Ring
Shank Neck Length
Between 0.197 inches and 0.217 inches
Stud Shank Major Diameter
0.240 inches
Turnlock Stud Head Style
Fillister
Turnlock Stud Shank Style
Stud shank
Diameter
Between 0.365 inches and 0.385 inches
