AN175C11 Close Tolerance Bolt

Product Series: AN
ECCN: EAR99
Schedule: 7318.15.8085

Price per Unit $48.51

Units per Pack 1

Price per Pack $48.51

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 1

Total Unit Quantity:

Total Packs 1

Total Price $48.51

Add item to quote

Head Style

Hexagon

Material

Stainless Steel

Thread Class

3a

Fastener Length: Between 1.202 inches and 1.248 inches
Grip Diameter: Between 0.3112 inches and 0.3117 inches
Grip Length: Between 0.667 inches and 0.697 inches
Head Height: Between 0.172 inches and 0.204 inches
Specification Data: 88044-an175 government standard
Thread Diameter: 0.312 inches
Thread Direction: Right-hand
Thread Length: 0.635 inches
Thread Qty Per Inch (tpi): 24
Thread Series Designator: Unf (fine thread)
Width Between Flats: 0.58 inches
