AN24-15 Clevis Bolt

NSN: 5306-00-156-2699
Product Series: AN
ECCN: EAR99
Schedule: 7318.15.2000

Price per Unit $2.70

Units per Pack 20

Price per Pack $54.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 20

Total Unit Quantity:

Total Packs 1

Total Price $54.00

Add item to quote

Head Style

Button

Material

Steel comp

Surface Treatment

Qq-p-416 type 2 cl 3 federal specification single treatment response

Thread Class

Departure From Cited Document: Thread t per mil-s-7742 except major diameter is not to exceed max allow shank bolt dia
Distance From Head Largest Surface To Shank Hole Center: 0.813 inches first hole
Fastener Length: Between 0.959 inches and 0.979 inches
Groove Diameter: 0.196 inches
Hardness Rating: 26.0 rockwell c and 32.0 rockwell c
Head Height: 0.125 inches
Internal Drive Style: Slot
Material Specification: Mil-b-6812 military specification all material responses
Min. Tensile Strength (psi): 125000 pounds per square inch
Shank Unthreaded Hole Diameter: 0.076 inches first hole and 0.086 inches first hole
Single Shear Strength: 3680 pounds per square inch
Thread Diameter: 0.250 inches
Thread Direction: Right-hand
Thread Length: Between 0.324 inches and 0.364 inches
Thread Qty Per Inch (tpi): 28
Thread Series Designator: Unf (fine thread)
Head Diameter: 0.500 inches
