AN24-25 Clevis Bolt

AN24-25 Clevis Bolt (2)

AN24-25 Clevis Bolt (3)

AN24-25 Clevis Bolt (4)

AN24-25 Clevis Bolt (5)

AN24-25 Clevis Bolt (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

AN24-25 Clevis Bolt

Product Series: AN
ECCN: EAR99
Schedule: 7318.15.2000

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Head Style

Button

Material

Steel comp 4140 or steel comp 8740 or steel comp 8630 or steel comp 8735 or steel comp 4130 or steel comp 4037

Surface Treatment

type 2 cl 3 federal specification all treatment responses qq-p-416

Thread Class

3a

Thread Quantity Per Inch (tpi)

28

Distance From Head Largest Bearing Surface To Shank Hole Center: 1.298 inches first hole and 1.330 inches first hole
Fastener Length: 1.594 inches
Groove Diameter: Between 0.191 inches and 0.201 inches
Head Height: 0.125 inches
Internal Drive Style: Slot
Shank Unthreaded Hole Diameter: 0.076 inches first hole and 0.086 inches first hole
Thread Diameter: 0.250 inches
Thread Direction: Right-hand
Thread Length: 0.351 inches
Thread Series Designator: Unf (fine thread)
Head Diameter: 0.500 inches
