AN4-6A Machine Bolt

Product Series
AN
ECCN
EAR99
Schedule
7318.15.8085
Price per Unit $0.69
Units per Pack 50
Price per Pack $34.50
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 50

Total Unit Quantity:
Total Packs 1
Total Price $34.50
Add item to quote
Head Style
Hexagon
Material
Steel
Surface Treatment
Class 3 federal specification all treatment responses type 2 qq-p-416
Thread Class
3a
Fastener Length
0.781 inches
Features
Finished head
Features Provided
Finished head
Grip Length
0.383 inches
Hardness Rating
26.0 rockwell c and 32.0 rockwell c
Head Height
Between 0.140 inches and 0.172 inches
Min. Tensile Strength (psi)
125000 pounds per square inch
Thread Diameter
0.250 inches
Thread Direction
Right-hand
Thread Length
0.397 inches
Thread Qty Per Inch (tpi)
28
Thread Series Designator
Unf (fine thread)
Width Between Flats
Between 0.428 inches and 0.440 inches
