AN515-6-8 Machine Screw
AN515-6-8 Machine Screw (2)
AN515-6-8 Machine Screw (3)
AN515-6-8 Machine Screw (4)
AN515-6-8 Machine Screw (5)
AN515-6-8 Machine Screw (6)
AN515-6-8 Machine Screw
AN515-6-8 Machine Screw (2)
AN515-6-8 Machine Screw (3)
AN515-6-8 Machine Screw (4)
AN515-6-8 Machine Screw (5)
AN515-6-8 Machine Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

AN515-6-8 Machine Screw

Product Series
AN
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $0.56
Units per Pack 100
Price per Pack $56.00
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:
Total Packs 1
Total Price $56.00
Add item to quote
Head Style
Round
Surface Treatment
Cl 3 federal specification single treatment response type 1 qq-p-416
Thread Class
2a
Fastener Length
0.500 inches
Head Height
0.103 inches
Internal Drive Style
Cross recess type 1
Min. Tensile Strength (psi)
55000 pounds per square inch
Screw Material
Steel
Screw Material Specification
Qq-s-630 federal specification 2nd material response or qq-s-631 federal specification 2nd material response or qq-s-634 federal specification 2nd material response
Thread Diameter
0.138 inches
Thread Direction
Right-hand
Thread Length
Between 0.438 inches and 0.500 inches
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unc (coarse thread)
Head Diameter
Between 0.240 inches and 0.260 inches
