AN515-6R7 Machine Screw

Product Series: AN
ECCN: EAR99
Schedule: 7318.15.2091

Price per Unit $0.68

Units per Pack 50

Price per Pack $34.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 50

Total Unit Quantity:

Total Packs 1

Total Price $34.00

Add item to quote

Head Style

Round

Material

Steel comp

Surface Treatment

Class 3 federal specification single treatment response type 1 qq-p-416

Thread Class

2a

Fastener Length: Between 0.406 inches and 0.437 inches
Head Height: 0.103 inches
Internal Drive Style: Cross recess type 1
Material Specification: Qq-s-633 federal specification single material response
Min. Tensile Strength (psi): 55000 pounds per square inch
Thread Diameter: 0.138 inches
Thread Direction: Right-hand
Thread Length: Between 0.406 inches and 0.437 inches
Thread Qty Per Inch (tpi): 32
Thread Series Designator: Unc (coarse thread)
Head Diameter: Between 0.24 inches and 0.26 inches
