AN526C1032R9 Machine Screw

Product Series: AN
ECCN: EAR99
Schedule: 7318.15.2091

Price per Unit $0.46

Units per Pack 100

Price per Pack $46.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:

Total Packs 1

Total Price $46.00

Add item to quote

Head Style

Button

Material

Steel

Thread Class

2a

Fastener Length: Between 0.531 inches and 0.562 inches
Head Height: 0.118 inches
Internal Drive Style: Cross recess type 1
Material Specification: Mil-s-7720 military specification 1st material response or qq-s-763 federal specification 2nd material response
Thread Diameter: 0.190 inches
Thread Direction: Right-hand
Thread Length: Between 0.469 inches and 0.531 inches
Thread Qty Per Inch (tpi): 32
Thread Series Designator: Unf (fine thread)
Head Diameter: Between 0.425 inches and 0.448 inches
