AN565AC8H12 Setscrew

AN565AC8H12 Setscrew (2)

AN565AC8H12 Setscrew (3)

AN565AC8H12 Setscrew (4)

AN565AC8H12 Setscrew (5)

AN565AC8H12 Setscrew (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

AN565AC8H12 Setscrew

Product Series: AN
ECCN: EAR99
Schedule: 7318.15.2091

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Head Style

Headless

Surface Treatment

Qq-p-35 federal specification single treatment response

Thread Class

3a

Fastener Length: 0.750 inches
Internal Drive Style: Hexagon
Material Specification: Mil-s-7720 military specification 1st material response or mil-s-18732 military specification 2nd material response
Point Style: Flat
Thread Diameter: 0.164 inches
Thread Direction: Right-hand
Thread Length: 0.75 inches
Thread Qty Per Inch (tpi): 32
Thread Series Designator: Unc (coarse thread)
Width Across Flats: Between 0.078 inches and 0.079 inches
