AN565D6H4 Setscrew
AN565D6H4 Setscrew (2)
AN565D6H4 Setscrew (3)
AN565D6H4 Setscrew (4)
AN565D6H4 Setscrew (5)
AN565D6H4 Setscrew (6)
AN565D6H4 Setscrew
AN565D6H4 Setscrew (2)
AN565D6H4 Setscrew (3)
AN565D6H4 Setscrew (4)
AN565D6H4 Setscrew (5)
AN565D6H4 Setscrew (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

AN565D6H4 Setscrew

Product Series
AN
ECCN
EAR99
Schedule
7318.15.9000
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Headless (setscrew)
Material
Steel comp 4037 or steel comp 4137 or steel comp 4140 or steel comp 8630 or steel comp 8740
Thread Class
3a
Fastener Length
0.250 inches
Hardness Rating
45.0 rockwell c and 53.0 rockwell c
Internal Drive Style
Hexagon
Material Specification
66 federal standard all material responses
Point Style
Cup
Thread Diameter
0.138 inches
Thread Direction
Right-hand
Thread Length
0.250 inches
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unc (coarse thread)
Width Across Flats
Between 0.062 inches and 0.063 inches
