AN565FC428H12 Setscrew
AN565FC428H12 Setscrew (2)
AN565FC428H12 Setscrew (3)
AN565FC428H12 Setscrew (4)
AN565FC428H12 Setscrew (5)
AN565FC428H12 Setscrew (6)
AN565FC428H12 Setscrew
AN565FC428H12 Setscrew (2)
AN565FC428H12 Setscrew (3)
AN565FC428H12 Setscrew (4)
AN565FC428H12 Setscrew (5)
AN565FC428H12 Setscrew (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

AN565FC428H12 Setscrew

Product Series
AN
ECCN
EAR99
Schedule
7318.15.2091
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Headless (setscrew)
Material
Steel comp 303 or steel comp 303se
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
3a
Fastener Length
Between 0.739 inches and 0.761 inches
Internal Drive Style
Hexagon
Material Specification
Astm a582 assn standard single material response
Nondefinitive Specification/std Data
1 type and 3 style
Point Style
Oval
Thread Diameter
0.250 inches
Thread Direction
Right-hand
Thread Length
Between 0.739 inches and 0.761 inches
Thread Qty Per Inch (tpi)
28
Thread Series Designator
Unf (fine thread)
Width Across Flats
Between 0.125 inches and 0.127 inches
