AN807-4D Straight Tube To Hose Adapter

Product Series: AN
ECCN: EAR99

Price per Unit $34.60

Units per Pack 1

Price per Pack $34.60

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 1

Total Unit Quantity:

Total Packs 1

Total Price $34.60

Add item to quote

Material

Aluminum alloy 2014

Surface Treatment

Mil-a-8625 military specification single treatment response outside

Thread Class

3a 1st end bulkhead

Thread Size

0.438 inches 1st end

Connection Style: Flared (tube) 1st end
Connection Type: Unthreaded external hose 2nd end
Inside Diameter Hose Accommodated: 0.250 inches 2nd end
Material Specification: T6 federal specification single material response qq-a-225/4
Nominallength: 2.812 inches
Outside Diameter Tube Accommodated: 0.250 inches 1st end
Seat Angle: 37.0 degrees 1st end
Special Features: Grumman a01 aircraft
Specification Data: 88044-an807 government standard and 81343-as4843/1 professional/industrial association standard
Thread Series Designator: Unjf (fine thread with external controlled root radius) 1st end bulkhead
