AN832-6 Straight Tube To Boss Adapter

Product Series: AN
ECCN: EAR99
Schedule: 7326.90.8695

Price per Unit $41.51

Units per Pack 1

Price per Pack $41.51

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 1

Total Unit Quantity:

Total Packs 1

Total Price $41.51

Add item to quote

Material

Steel comp 1137

Surface Treatment

Class 2 federal specification single treatment response type 1 qq-p-416

Thread Class

3a all ends

Thread Size

0.562 inches center bulkhead

Connection Style: Flared with gasket seal (boss) 2nd end
Connection Type: Threaded external tube 1st end
Material Specification: 66 federal standard single material response
Nominallength: 2.219 inches
Outside Diameter Tube Accommodated: 0.375 inches 1st end
Part Name Assigned By Controlling Agency: 3/8 bulkhead and universal union-flared tube
Seat Angle: 37 degrees 1st end
Specification Data: 81343-as4841 professional/industrial association standard
Thread Series Designator: Unjf (fine thread with external controlled root radius) center bulkhead
