AS21919WDG12 Loop Clamp

ECCN
EAR99
Schedule
7616.10.9090
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Rubber chloroprene class cr cushion
Surface Treatment
-1l-c-5541 military specification single treatment response band
Center To Center Distance Between Loop And Mounting Hole
Between 0.830 inches and 0.860 inches
Cushioning Environmental Protection
Weather resistant
Distance From Loop Center To Tongue End
1.063 inches
Loop Inside Diameter
Between 0.735 inches and 0.765 inches
Material Specification
Ams 3209 assn standard single material response cushion
Material Thickness
0.050 inches
Nondefinitive Specification/std Data
4 type and a class
Overall Width
Between 0.490 inches and 0.510 inches
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
0.204 inches
