AS5168D12 Threaded Tube Fitting Plug
AS5168D12 Threaded Tube Fitting Plug (2)
AS5168D12 Threaded Tube Fitting Plug (3)
AS5168D12 Threaded Tube Fitting Plug (4)
AS5168D12 Threaded Tube Fitting Plug (5)
AS5168D12 Threaded Tube Fitting Plug
AS5168D12 Threaded Tube Fitting Plug (2)
AS5168D12 Threaded Tube Fitting Plug (3)
AS5168D12 Threaded Tube Fitting Plug (4)
AS5168D12 Threaded Tube Fitting Plug (5)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

AS5168D12 Threaded Tube Fitting Plug

ECCN
EAR99
Schedule
7307.99.4000
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Aluminum alloy 2014 or aluminum alloy 7075
Overall Length
Between 1.203 inches and 1.234 inches
Surface Treatment
Blue military specification single treatment response cl 2 type 2 mil-a-8625
Thread Class
3a external
Thread Size
1.062 inches external
Connection Style
Flared
Head Height
0.341 inches
Iii End Application
Mrap buffalo mk2a2
Material Specification
T73 federal specification 2nd material response t6 federal specification 1st material response or qq-a-367 qq-a-367
Seat Angle
37.0 degrees
Special Features
Grumman aerospace corporation supports a10 aircraft
Style Designator
Should not be considered as a separating characteristic) tube fitting flared (note: drilled hole is optional plug
Thread Direction
Right-hand external
Thread Qty Per Inch (tpi)
12 external
Thread Series Designator
Un external
