AS5168J03 Threaded Tube Fitting Plug
AS5168J03 Threaded Tube Fitting Plug (2)
AS5168J03 Threaded Tube Fitting Plug (3)
AS5168J03 Threaded Tube Fitting Plug (4)
AS5168J03 Threaded Tube Fitting Plug (5)
AS5168J03 Threaded Tube Fitting Plug
AS5168J03 Threaded Tube Fitting Plug (2)
AS5168J03 Threaded Tube Fitting Plug (3)
AS5168J03 Threaded Tube Fitting Plug (4)
AS5168J03 Threaded Tube Fitting Plug (5)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

AS5168J03 Threaded Tube Fitting Plug

ECCN
EAR99
Schedule
7307.99.4000
Price per Unit $21.48
Units per Pack 2
Price per Pack $42.96
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 2

Total Unit Quantity:
Total Packs 1
Total Price $42.96
Add item to quote
Material
Steel comp 304 or steel comp 316
Overall Length
0.672 inches
Surface Treatment
Mil-s-5002 military specification single treatment response
Thread Class
3a external
Thread Size
0.375 inches external
Connection Style
Flared
Head Height
Between 0.178 inches and 0.208 inches
Material Specification
66 federal standard single material response
Maximum Operating Pressure
3000.0 pounds per square inch
Maximum Operating Temp
250.0 degrees fahrenheit
Media For Which Designed
Air
Seat Angle
37.0 degrees
Specification Data
81349-mil-f-5509 government specification
Style Designator
Should not be considered as a separating characteristic) tube fitting flared (note: drilled hole is optional plug
Thread Direction
Right-hand external
Thread Series Designator
Unf (fine thread) external
