BACC10DK3 Loop Clamp

Product Series
BAC
ECCN
EAR99
Schedule
7616.10.9090
Price per Unit $2.89
Units per Pack 25
Price per Pack $72.25
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 25

Total Unit Quantity:
Total Packs 1
Total Price $72.25
Add item to quote
Material
Plastic polyhexamethylene adipamide band
Center To Center Distance Between Loop And Mounting Hole
Between 0.483 inches and 0.513 inches
Distance From Loop Center To Tongue End
0.748 inches
Loop Inside Diameter
Between 0.182 inches and 0.192 inches
Material Specification
L-p-410com+6/6 federal specification single material response band
Material Thickness
Between 0.060 inches and 0.075 inches
Overall Width
Between 0.490 inches and 0.510 inches
Special Features
Color orange
Specification Data
81205-bacc10dk manufacturers specification
Style Designator
Single loop
Tongue Hole Type
unthreaded round
Diameter
Between 0.199 inches and 0.203 inches
