BACN10JC3 Self-Locking Hexagon Nut

Product Series: BAC
ECCN: EAR99
Schedule: 7318.16.0000

Price per Unit $3.89

Units per Pack 10

Price per Pack $38.90

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $38.90

Add item to quote

Material

Steel

Surface Treatment

Cl2 federal specification single treatment response ty2 qq-p-416

Thread Class

3b

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.190 inches

Bearing Surface Type: Chamfered
Inside Width Across Flats: Between 0.297 inches and 0.305 inches
Locking Feature: Prevailing torque all metal design
Nut Height: 0.190 inches
Nut Style: Internal or external wrenching hexagon
Tempurature Rating: 450.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
Width Across Flats: Between 0.367 inches and 0.376 inches
Lubrication: Dry film lubricant
