BACN10TS3-16 Self-Locking Nutplate

Product Series: BAC
ECCN: EAR99
Schedule: 7318.16.0000

Price per Unit $4.16

Units per Pack 10

Price per Pack $41.60

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $41.60

Add item to quote

Material

Plastic except threads

Surface Treatment

Class 3 federal specification all treatment responses threads type 2 qq-p-416

Thread Class

Thread Series

Unf (fine thread)

Thread Size

0.190 inches

Center To Center Distance Between Mounting Holes Along Width: Between 1.000 inches and 1.030 inches
Distance From Base To Center Of Aperture: Between 0.280 inches and 0.340 inches
Locking Feature: Prevailing torque all metal design
Material Specification: L-p-395 6/6 type 1 class 1 or 2 federal specification single material response except threads
Mounting Hole Arrangement Style: 2 holes
Mounting Hole Diameter: 0.133 mils and 0.143 centimeters
Nut Length: Between 2.010 inches and 2.190 inches
Nut Mounting Provision: Straight holes
Nut Style: Plate
Plate Thickness: Between 0.110 inches and 0.150 inches
Plate Width: Between 1.440 inches and 1.590 inches
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
