BACN11AG4 Clip-On Nut

Product Series: BAC
ECCN: EAR99
Schedule: 7318.16.0085

Price per Unit $2.01

Units per Pack 25

Price per Pack $50.25

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 25

Total Unit Quantity:

Total Packs 1

Total Price $50.25

Add item to quote

Material

Steel comp 8740 or steel comp 8630 or steel comp 4027 or steel comp 4037

Surface Treatment

class 2 federal specification single treatment response type ii qq-p-416

Thread Class

3b

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.250 inches

Hardness Rating: Between 36.0 rockwell c and 44.0 rockwell c
Locking Feature: Prevailing torque all metal design
Material Specification: Ams6322 assn standard single material response or ams6325 assn standard single material response or ams6280 assn standard single material response or astma304 assn standard single material response or ams6300 assn standard single material respons
Nut Height: Between 0.204 inches and 0.219 inches
Tempurature Rating: 450.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 28
Width Across Flats: Between 0.304 inches and 0.316 inches
