CCR244SS-3-04 Blind Rivet

Product Series
CR
ECCN
EAR99
Schedule
7318.23.0000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flush (flat) countersunk (included angle - less than 135 degrees w or w/o chamfer)
Material
Steel comp 1008 stem
Surface Treatment
Qq-p-416 type 2 cl 2 federal specification single treatment response sleeve
Countersink Angle
Between 99.0 degrees and 101.0 degrees
Expansion Device
Serrated stem-type w
Grip Length
Between 0.188 inches and 0.250 inches
Head Major Diameter
0.148 inches
Heat Treatment
Annealed sleeve
Shank Diameter
0.094 inches
Shank Style
Self-plugging high clinch shank
