CCR264CS3-10 Blind Rivet

Product Series
CR
ECCN
EAR99
Schedule
7318.23.0000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flush (flat) countersunk (included angle - less than 135 degrees w or w/o chamfer)
Material
Steel comp 305 stem
Surface Treatment
Qq-p-35 federal specification single treatment response stem
Countersink Angle
Between 99.0 degrees and 101.0 degrees
Expansion Device
Threaded stem
Fastener Length
0.781 inches
Grip Length
Between 0.563 inches and 0.625 inches
Head Major Diameter
0.183 inches
Material Specification
Ams 5731 assn standard single material response sleeve
Shank Diameter
Between 0.092 inches and 0.097 inches
Shank Style
Self-plugging high clinch shank
Lubrication
Dry film
