CR3212-4-05 Blind Rivet

Product Series
CR
ECCN
EAR99
Schedule
7616.10.3000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flush (flat) countersunk
Material
Aluminum alloy 5056 sleeve
Surface Treatment
Class 2 federal specification single treatment response stem type 2 qq-p-416
Countersink Angle
Between 99 degrees and 101 degrees
Expansion Device
Serrated stem-type w
Fastener Length
Between 0.402 inches and 0.422 inches
Grip Length
Between 0.251 inches and 0.312 inches
Head Major Diameter
0.229 inches
Material Specification
Qq-a-430 federal specification single material response sleeve
Shank Diameter
Between 0.125 inches and 0.129 inches
Shank Style
Self-plugging mechanically locked stem
Special Features
Ns
