CR3212-5-04 Blind Rivet

Product Series
CR
ECCN
EAR99
Schedule
7616.10.3000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flush (flat) countersunk
Material
Steel comp 8740 stem
Surface Treatment
Class 2 federal specification all treatment responses stem type 2 qq-p-416
Countersink Angle
Between 99 degrees and 101 degrees
Expansion Device
Serrated stem-type w
Fastener Length
Between 0.345 inches and 0.365 inches
Grip Length
Between 0.188 inches and 0.250 inches
Head Major Diameter
0.29 inches
Material Specification
Qq-a-430 federal specification single material response sleeve
Shank Diameter
Between 0.156 inches and 0.16 inches
Shank Style
Self-plugging mechanically locked stem
Special Features
Ns
