CR3524-5-05 Blind Rivet

Product Series
CR
ECCN
EAR99
Schedule
7318.23.0000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flush (flat) countersunk (included angle - less than 135 degrees w or w/o chamfer)
Material
Nickel alloy 400 sleeve
Countersink Angle
Between 98.5 degrees and 101.5 degrees
Expansion Device
Serrated stem-type w
Fastener Length
Between 0.388 inches and 0.418 inches
Grip Length
Between 0.251 inches and 0.312 inches
Head Major Diameter
0.247 inches
Material Specification
Qq-n-281 federal specification single material response sleeve
Shank Diameter
Between 0.156 inches and 0.160 inches
Shank Style
Self-plugging mechanically locked stem
