HL75-6AW Collar

Product Series: HL
ECCN: EAR99
Schedule: 7616.10.1000

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Steel comp 303se

Surface Treatment

Class 3 federal specification single treatment response type 1 qq-p-416

Thread Class

3b

Thread Size

0.19 inches

Collar Inside Diameter: 0.255 inches
Collar Outside Diameter: Between 0.355 inches and 0.365 inches
Collar Style: Threaded (break off) type
Collarheight: Between 0.432 inches and 0.452 inches
Material Specification: Qq-s-764 federal specification single material response
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
Thread Series Designator: Unjf (fine thread with external controlled root radius)
Lubrication: Grease film
