HL94-8 Pin-Rivet Collar

Product Series: HL
ECCN: EAR99
Schedule: 7318.23.0000

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Steel comp 303se

Surface Treatment

Qq-p-416 type 2 class 3 federal specification single treatment response

Thread Class

3b

Thread Size

0.250 inches

Collar Inside Diameter: Between 0.268 inches and 0.272 inches
Collar Outside Diameter: Between 0.418 inches and 0.422 inches
Collar Style: Threaded (break off) type
Collarheight: Between 0.532 inches and 0.552 inches
Material Specification: Astm a582 assn standard single material response
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 28
Thread Series Designator: Unjf (fine thread with external controlled root radius)
Lubrication: hi-shear corp specification 305 cetyl alcohol
