M25988/1-010 O-Ring
M25988/1-010 O-Ring (2)
M25988/1-010 O-Ring (3)
M25988/1-010 O-Ring (4)
M25988/1-010 O-Ring (5)
M25988/1-010 O-Ring (6)
M25988/1-010 O-Ring
M25988/1-010 O-Ring (2)
M25988/1-010 O-Ring (3)
M25988/1-010 O-Ring (4)
M25988/1-010 O-Ring (5)
M25988/1-010 O-Ring (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

M25988/1-010 O-Ring

ECCN
EAR99
Schedule
4016.93.0000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Rubber fluorosilicone class fq
Center Hole Diameter
Between 0.232 inches and 0.246 inches
Cross-sectional Height
Between 0.067 inches and 0.073 inches
Elongation Percentage
125
Hardness Rating
70.0 shore durometer a
Outside Diameter
0.379 inches
Part Name Assigned By Controlling Agency
fluorosilicone elastomer o-ring
Tempurature Rating
-80.0 degrees fahrenheit and 350.0 degrees fahrenheit
