M45913/1-010FS3 Self-Locking Hexagon Nut

ECCN: EAR99
Schedule: 7318.16.0000

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Steel comp 303 nut

Surface Treatment

Qq-p-35 federal specification single treatment response nut

Thread Class

2b

Thread Series

Unf (fine thread)

Thread Size

0.190 inches

Bearing Surface Finish: 125.0 microinches
Bearing Surface Type: Chamfered
End Application: 40/105mm rack; aircraft
Locking Feature: Prevailing torque with nonmetallic insert
Nut Height: Between 0.229 inches and 0.249 inches
Nut Style: Hexagon
Specification Data: 81349-mil-dtl-45913/1 government specification
Tempurature Rating: 250.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
Width Across Flats: Between 0.367 inches and 0.376 inches
