M81824/1-1 Conductor Splice
M81824/1-1 Conductor Splice (2)
M81824/1-1 Conductor Splice (3)
M81824/1-1 Conductor Splice (4)
M81824/1-1 Conductor Splice (5)
M81824/1-1 Conductor Splice
M81824/1-1 Conductor Splice (2)
M81824/1-1 Conductor Splice (3)
M81824/1-1 Conductor Splice (4)
M81824/1-1 Conductor Splice (5)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

M81824/1-1 Conductor Splice

ECCN
EAR99
Schedule
7326.90.8695
Price per Unit $6.09
Units per Pack 10
Price per Pack $60.90
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:
Total Packs 1
Total Price $60.90
Add item to quote
Material
Plastic polyvinylidene fluoride insulation
Overall Length
1.100 inches
Basic Shape Style
Crimp
Conductor Accommodation Type
Recessed barrel all ends
Electrical Insulation Feature
Insulating sleeve
Features
Meltable plastic insert
Features Provided
Meltable plastic insert
Identification Code Color
Red
Material Specification
Mil-i-23053/8 military specification single material response insulation
Maximum Conductor Size Accommodated
20 awg
