M85052/1-12 Loop Clamp
M85052/1-12 Loop Clamp (2)
M85052/1-12 Loop Clamp (3)
M85052/1-12 Loop Clamp (4)
M85052/1-12 Loop Clamp (5)
M85052/1-12 Loop Clamp (6)
M85052/1-12 Loop Clamp
M85052/1-12 Loop Clamp (2)
M85052/1-12 Loop Clamp (3)
M85052/1-12 Loop Clamp (4)
M85052/1-12 Loop Clamp (5)
M85052/1-12 Loop Clamp (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

M85052/1-12 Loop Clamp

ECCN
EAR99
Schedule
8539.29.2500
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel comp 631 band
Surface Treatment
Qq-p-35 federal specification single treatment response band
Center To Center Distance Between Loop And Mounting Hole
Between 0.820 inches and 0.850 inches
Cushioning Environmental Protection
Fuel resistant and hydraulic fluid
Distance From Loop Center To Tongue End
1.053 inches
Loop Inside Diameter
0.750 inches
Material Specification
Mil-s-25043 military specification single material response band
Material Thickness
Between 0.030 inches and 0.034 inches
Overall Width
0.500 inches
Special Features
Cushion is ozone resistant
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
Between 0.194 inches and 0.209 inches
