MS14101-4P Plain Self-Aligning Bearing
MS14101-4P Plain Self-Aligning Bearing (2)
MS14101-4P Plain Self-Aligning Bearing (3)
MS14101-4P Plain Self-Aligning Bearing (4)
MS14101-4P Plain Self-Aligning Bearing
MS14101-4P Plain Self-Aligning Bearing (2)
MS14101-4P Plain Self-Aligning Bearing (3)
MS14101-4P Plain Self-Aligning Bearing (4)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS14101-4P Plain Self-Aligning Bearing

Product Series
MS
ECCN
EAR99
Schedule
8483.30.8090
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel comp 440c inner member
Surface Treatment
Class 2 federal specification single treatment response outer race member type 2 qq-p-416
Bore Diameter
Between 0.2495 inches and 0.2500 inches
Hardness Rating
55.0 rockwell c inner member and 62.0 rockwell c inner member
Inner Member Width
Between 0.3410 inches and 0.3430 inches
Lubrication Feature
Self-lubricating liner race liner
Material Specification
Ams 5630 assn standard single material response inner member
Outer Member Outside Diameter
Between 0.6557 inches and 0.6562 inches
Outer Member Width
Between 0.2450 inches and 0.2550 inches
Special Features
Passivation optional on ball
Static Radial Load Rating
6040 pounds
Style Designator
With insert and/or liner with staking groove
