MS14102-5 Plain Self-Aligning Bearing
MS14102-5 Plain Self-Aligning Bearing (2)
MS14102-5 Plain Self-Aligning Bearing (3)
MS14102-5 Plain Self-Aligning Bearing (4)
MS14102-5 Plain Self-Aligning Bearing (5)
MS14102-5 Plain Self-Aligning Bearing (6)
MS14102-5 Plain Self-Aligning Bearing
MS14102-5 Plain Self-Aligning Bearing (2)
MS14102-5 Plain Self-Aligning Bearing (3)
MS14102-5 Plain Self-Aligning Bearing (4)
MS14102-5 Plain Self-Aligning Bearing (5)
MS14102-5 Plain Self-Aligning Bearing (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS14102-5 Plain Self-Aligning Bearing

Product Series
MS
ECCN
EAR99
Schedule
7318.15.5030
Price per Unit $35.96
Units per Pack 1
Price per Pack $35.96
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 1

Total Unit Quantity:
Total Packs 1
Total Price $35.96
Add item to quote
Material
Steel
Bore Diameter
Between 0.3120 inches and 0.3125 inches
Inner Member Width
Between 0.4350 inches and 0.4370 inches
Material Specification
Ams 5630 assn standard single material response inner member
Outer Member Outside Diameter
Between 0.6870 inches and 0.6875 inches
Outer Member Width
Between 0.3120 inches and 0.3220 inches
Part Name Assigned By Controlling Agency
Outer ring -65 degrees to 325 degrees chamfered wide low speed self-aligning self lubricatging plain bearing
Static Radial Load Rating
9400 pounds
Style Designator
With insert and/or liner
