MS14103-16 Plain Self-Aligning Bearing

NSN
3120-01-136-3573
Product Series
MS
ECCN
EAR99
Schedule
8483.30.8090
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel inner member
Bore Diameter
Between 0.9995 inches and 1.0000 inches
Hardness Rating
28.0 rockwell c outer race member and 37.0 rockwell c outer race member
Inner Member Width
Between 1.3730 inches and 1.3750 inches
Outer Member Outside Diameter
Between 2.1245 inches and 2.1250 inches
Outer Member Width
Between 1.0000 inches and 1.0100 inches
Static Radial Load Rating
104000 pounds
Style Designator
With insert and/or liner with staking groove
