MS14144L8 Self-Locking Extended Washer Nut

Product Series: MS
ECCN: EAR99
Schedule: 7318.22.0000

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote

Material

Steel

Surface Treatment

Qq-p-416 federal specification single treatment response

Thread Class

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.500 inches

Criticality Code Justification: Feat
Locking Feature: Prevailing torque all metal design
Nut Style: Slotted hexagon
Overall Height: Between 0.548 inches and 0.578 inches
Special Features: Flightsafety critical aircraft part
Surface Finish: 125.0 microinches
Tempurature Rating: 450 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 20
Washer Outside Diameter: 0.770 inches
Washer Thickness: 0.070 inches
Width Across Flats: Between 0.554 inches and 0.566 inches
Lubrication: Dry film lubricant
