MS14182L08 Self-Locking Extended Washer Nut

Product Series
MS
ECCN
EAR99
Schedule
7318.22.0000
Price per Unit $56.75
Units per Pack 1
Price per Pack $56.75
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 1

Total Unit Quantity:
Total Packs 1
Total Price $56.75
Add item to quote
Material
Nickel alloy 718
Surface Treatment
Cl 1 federal specification single treatment response qq-n-290
Thread Class
3b
Thread Series
Unjf (fine thread with external controlled root radius)
Thread Size
0.500 inches
Drive Point Quantity
20
Locking Feature
Prevailing torque all metal design
Material Specification
Ams 5662 assn standard single material response or ams 5663 assn standard single material response
Nut Style
Spline drive
Overall Height
0.575 inches
Tempurature Rating
800.0 degrees fahrenheit
Thread Direction
Right-hand
Thread Qty Per Inch (tpi)
20
Washer Outside Diameter
0.879 inches
Washer Thickness
0.060 inches
Lubrication
Dry film lubricant
