MS16562-140 Spring Pin
MS16562-140 Spring Pin (2)
MS16562-140 Spring Pin (3)
MS16562-140 Spring Pin (4)
MS16562-140 Spring Pin (5)
MS16562-140 Spring Pin (6)
MS16562-140 Spring Pin
MS16562-140 Spring Pin (2)
MS16562-140 Spring Pin (3)
MS16562-140 Spring Pin (4)
MS16562-140 Spring Pin (5)
MS16562-140 Spring Pin (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS16562-140 Spring Pin

Product Series
MS
ECCN
EAR99
Schedule
7318.29.0000
Price per Unit $0.30
Units per Pack 100
Price per Pack $30.00
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:
Total Packs 1
Total Price $30.00
Add item to quote
Material
Steel comp 1070 or steel comp 1074 or steel comp 1080 or steel comp 1086 or steel comp 1095
Overall Length
Between 0.485 inches and 0.515 inches
Surface Treatment
Cl2 national specification single treatment response dod-p-16232
Hardness Rating
46.0 rockwell c and 53.0 rockwell c
Material Specification
66 federal standard all material responses
Material Thickness
0.042 inches
Shear Strength
4400 double pound
Style Designator
Slotted
Diameter
Between 0.194 inches and 0.199 inches
