MS16562-18 Spring Pin

Product Series
MS
ECCN
EAR99
Schedule
7318.29.0000
Price per Unit $0.43
Units per Pack 100
Price per Pack $43.00
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:
Total Packs 1
Total Price $43.00
Add item to quote
Material
Steel
Overall Length
Between 0.735 inches and 0.765 inches
Surface Treatment
Ty2 cl2 federal specification single treatment response qq-p-416
Hardness Rating
46.0 rockwell c and 53.0 rockwell c
Material Specification
66 federal standard all material responses
Material Thickness
0.018 inches
Shear Strength
650 double pound
Style Designator
Slotted
Diameter
Between 0.083 inches and 0.086 inches
