MS16562-202 Spring Pin

Product Series: MS
ECCN: EAR99
Schedule: 7320.20.5060

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Steel comp 410 or steel comp 420

Overall Length

Between 0.423 inches and 0.453 inches

Surface Treatment

Astm a380 assn standard single treatment response

Hardness Rating: 43.0 rockwell c and 52.0 rockwell c
Material Specification: 66 federal standard all material responses
Material Thickness: 0.018 inches
Shear Strength: 650 double pound
Style Designator: Slotted
Surface Finish: 80.0 microinches outside diameter
Diameter: Between 0.083 inches and 0.086 inches
