MS16562-235 Spring Pin

Product Series
MS
ECCN
EAR99
Schedule
7318.29.0000
Price per Unit $0.68
Units per Pack 50
Price per Pack $34.00
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 50

Total Unit Quantity:
Total Packs 1
Total Price $34.00
Add item to quote
Material
Steel comp
Overall Length
Between 0.610 inches and 0.640 inches
Surface Treatment
Astm a380 assn standard single treatment response
Hardness Rating
43.0 rockwell c and 52.0 rockwell c
Material Specification
66 federal standard all material responses
Material Thickness
0.040 inches
Shear Strength
4400 double pound
Style Designator
Slotted
Diameter
Between 0.194 inches and 0.199 inches
