MS16562-6 Spring Pin

Product Series
MS
ECCN
EAR99
Schedule
7318.29.0000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel comp
Overall Length
Between 0.485 inches and 0.515 inches
Surface Treatment
Ty2 cl2 federal specification single treatment response qq-p-416
Hardness Rating
46.0 rockwell c and 53.0 rockwell c
Material Specification
66 federal standard all material responses
Material Thickness
0.012 inches
Shear Strength
425 double pound
Style Designator
Slotted
Diameter
Between 0.066 inches and 0.069 inches
