MS16633-1021 Retaining Ring

Product Series: MS
ECCN: EAR99
Schedule: 7318.29.0000

Price per Unit $0.70

Units per Pack 50

Price per Pack $35.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 50

Total Unit Quantity:

Total Packs 1

Total Price $35.00

Add item to quote

Material

Aisi c1066 thru c1090 or sae 1070 thru 1090 fed standard 66 fed steel

Casehardening Indicator: Not casehardened
Cross Sectional Shape: Rectangular
Inside Diameter: 0.185 inches
Major Thickness: 0.025 inches
Material Hardness Rating: Between 66.5 rockwell superficial 30-n and 71.0 rockwell superficial 30-n
Ring Style: E
Usage Design: External
