MS16995-19B Socket Head Cap Screw
MS16995-19B Socket Head Cap Screw (2)
MS16995-19B Socket Head Cap Screw (3)
MS16995-19B Socket Head Cap Screw (4)
MS16995-19B Socket Head Cap Screw (5)
MS16995-19B Socket Head Cap Screw (6)
MS16995-19B Socket Head Cap Screw
MS16995-19B Socket Head Cap Screw (2)
MS16995-19B Socket Head Cap Screw (3)
MS16995-19B Socket Head Cap Screw (4)
MS16995-19B Socket Head Cap Screw (5)
MS16995-19B Socket Head Cap Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS16995-19B Socket Head Cap Screw

Product Series
MS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $2.70
Units per Pack 20
Price per Pack $54.00
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 20

Total Unit Quantity:
Total Packs 1
Total Price $54.00
Add item to quote
Head Style
Flat chamfer
Material
Steel comp 302 or steel comp 303 or steel comp 304 or steel comp 305 or steel comp 316
Surface Treatment
Cl 4 military specification single treatment response mil-c-13924
Thread Class
3a
Fastener Length
Between 0.595 inches and 0.625 inches
Hardness Rating
80.0 rockwell b
Head Height
Between 0.134 inches and 0.138 inches
Internal Drive Style
Hexagon
Material Specification
66 federal standard all material responses
Min. Tensile Strength (psi)
80000 pounds per square inch
Minimum Yield Strength
30000 pounds per square inch
Nondefinitive Specification/std Data
6 type
Special Features
Finish color black
Thread Diameter
0.138 inches
Thread Direction
Right-hand
Thread Length
Between 0.533 inches and 0.625 inches
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unc (coarse thread)
Width Across Flats
Between 0.109 inches and 0.111 inches
Head Diameter
Between 0.218 inches and 0.226 inches
