MS16995-3 Socket Head Cap Screw

Product Series
MS
ECCN
EAR99
Schedule
7318.15.9000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flat chamfer
Material
Stainless Steel
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
3a
Thread Quantity Per Inch (tpi)
56
Fastener Length
Between 0.345 inches and 0.375 inches
Hardness Rating
80.0 rockwell b
Head Height
Between 0.083 inches and 0.086 inches
Internal Drive Style
Hexagon
Material Specification
66 federal standard single material response
Min. Tensile Strength (psi)
80000 pounds per square inch
Minimum Yield Strength
30000 pounds per square inch
Nondefinitive Specification/std Data
6 type
Thread Diameter
0.086 inches
Thread Direction
Right-hand
Thread Length
Between 0.309 inches and 0.375 inches
Thread Series Designator
Unc (coarse thread)
Width Across Flats
Between 0.078 inches and 0.079 inches
Head Diameter
Between 0.134 inches and 0.140 inches
